FixedDataTable:React.js灵活快速延迟表格渲染?

前有科技后进阶 2024-11-30 06:25:03

大家好,很高兴又见面了,我是"高级前端‬进阶‬",由我带着大家一起关注前端前沿、深入前端底层技术,大家一起进步,也欢迎大家关注、点赞、收藏、转发,您的支持是我不断创作的动力。

什么是 FixedDataTable

Fixed-Data-Table-2 是 facebook/fixed-data-table 的延续, 后者存储库不再维护,并且有许多拉取请求(pull requests )等待处理。

本质上,FixDataTable 是一个 React 组件,用于以灵活、强大的方式构建和渲染数据,支持标准表格功能,例如:标题、列、行、标题分组以及固定位置和滚动列。

FixDataTable旨在处理数千行数据而不牺牲性能,平滑滚动是固定数据表的首要目标,同时代码架构具有高度的灵活性和可扩展性。FixedDataTable 的典型特点包括:

固定页眉和页脚固定列和可滚动列处理大量数据可变行高(具有自适应滚动位置)调整列大小高性能滚动可定制的样式跳转到行或列受控滚动 API 允许触摸支持

但是 FixDataTable 也有自己的一些局限性,比如:

FixDataTable 不提供布局重排机制或计算内容布局信息,例如:单元格内容的宽度和高度, 开发人员必须向表提供布局信息。FixDataTable 不处理数据排序,但是允许开发人员提供可排序、过滤或尾加载感知的数据获取器。FixDataTable 不获取数据

此版本的 FixDataTable 由 Schrödinger, Inc. 维护。它是 Facebook 的 FixDataTable 存储库的 fork 版本,可在 BSD 许可证下使用,同时对固定数据表的贡献和修改也受 BSD 许可证的约束。

如何使用 FixDataTable

首先使用 npm 安装 fixed-data-table-2:

npm install fixed-data-table-2

使用链接标签添加默认样式表 dist/fixed-data-table.css 或使用 CSS 模块导入它。

实现表格涉及三种组件类型,即 <Table/>、<Column/> 和 <Cell/>,而<Table /> 包含整个表的配置信息,例如:维度和行数。

const rows =[0,1,2]; <Table rowHeight={50} rowsCount={100} width={5000} height={5050} headerHeight={50} ... </Table>

<Column /> 定义表中一列的数据显示方式,包括该列的所有单元格行为。 不是直接操作每个单元格,而是将单元格组件作为 prop 传递给列,并且该列将为数据数组中的每个索引渲染一个单元格。

<Column header={<Cell>Col 1</Cell>} cell={<Cell>Column 1</Cell>} width={2000} />

列中的单元格组件将接收数据的当前数组索引作为 prop (this.props.rowIndex),使用它来访问每个单元格的正确值。

const rows = [0, 1, 2];<Column header={<Cell>Column 1</Cell>} cell={({ rowIndex, ...props }) => <Cell {...props}>{rows[rowIndex]}</Cell>} width={2000}/>;

如果 data 是对象数组,请为每列定义一个 columnKey 属性,它也将传递到该列中的所有单元格。

const rows = [ { someKey: "someValue" }, { someKey: "anotherValue" }, { someKey: "yetAnother" },];<Column header={<Cell>Col 1</Cell>} columnKey="someKey" cell={({ rowIndex, columnKey, ...props }) => ( <Cell {...props}>{rows[rowIndex][columnKey]}</Cell> )} width={2000}/>;

您可能会发现定义自定义单元格组件很有用,这些组件也可以传递到列:

const MyCustomCell = ({ isSpecial }) => ( <Cell>{isSpecial ? "I'm Special" : "I'm Not Special"}</Cell>);<Column header={<Cell>Col 3</Cell>} cell={<MyCustomCell isSpecial />} width={2000}/>;

下面是完整的代码示例:

import React from "react";import ReactDOM from "react-dom";import { Table, Column, Cell } from "fixed-data-table-2";import "fixed-data-table-2/dist/fixed-data-table.css";// 表data作为数组列表const rows = [ "first row", "second row", "third row", // .... and more];// 使用特殊prop的自定义单元实现const MyCustomCell = ({ mySpecialProp }) => ( <Cell> {mySpecialProp === "column2" ? "I'm column 2" : "I'm not column 2"} </Cell>);// 渲染表格ReactDOM.render( <Table rowHeight={50} rowsCount={rows.length} width={5000} height={5000} headerHeight={50} > <Column header={<Cell>Col 1</Cell>} cell={<Cell>Column 1 static content</Cell>} width={2000} /> <Column header={<Cell>Col 2</Cell>} cell={<MyCustomCell mySpecialProp="column2" />} width={1000} /> <Column header={<Cell>Col 3</Cell>} cell={({ rowIndex, ...props }) => ( <Cell {...props}>Data for column 3: {rows[rowIndex]}</Cell> )} width={2000} /> </Table>, document.getElementById("example"));参考资料

https://github.com/schrodinger/fixed-data-table-2

https://schrodinger.github.io/fixed-data-table-2/

https://schrodinger.github.io/fixed-data-table-2/example-reorder.html

https://www.material-react-table.com/blog/the-best-react-data-grid-table-libraries-with-material-design-in-2023
